Airtac 2L Solenoid Valve 2L03006FI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03006FI Technical Details
- Model: 2L03006FI
- Type: 2-position 3-way normally closed (pilot-operated)
- Port size: PT1/8 (G1/8 optional)
- Effective area ratio: 15% (improved flow dynamics)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage tolerance: ±10% (DC/AC variants available)
- Voltage options:
- DC12V (0.45A)
- DC24V (0.25A)
- AC110V 50/60Hz (7.5VA)
- AC220V 50/60Hz (6.5VA)
- Response time: ≤15ms (with 0.5MPa pressure)
- Seal material: HNBR (hydrogenated nitrile) for oil resistance
- Ambient temperature: -5℃ to 60℃ (operating fluid temp -20℃ to 70℃)
- Weight: 210g ±5g (without connector)
- Dimensions: 54mm(L) × 38mm(W) × 73mm(H) (including fittings)
- Port thread depth: 9.5mm (prevents overtightening)
- Protection rating: IP67 (dust/water resistant)
- Service life: ≥10 million cycles (under rated conditions)
High-speed industrial-grade solenoid valve featuring dynamic pressure compensation for stable operation under fluctuating loads. The encapsulated coil design provides enhanced moisture resistance, while the brass body with nickel plating ensures corrosion protection in harsh environments. Requires 5μm filtered air with lubrication (ISO 8573-1 class 4).
- Pneumatic clamping systems in CNC machinery
- Bottle capping/crimping automation lines
- Textile machinery tension control
- Semiconductor wafer handling robots
- Commercial coffee machine steam valves
- Electric vehicle battery cooling systems
Installation requirements:
Maintain ≤3° deviation from vertical mounting axis. Use copper-free
anti-seize compound on threads. Minimum 12mm clearance required
below valve for heat dissipation during continuous operation.
- Lubrication: Every 6 months (ISO VG32 turbine oil)
- Diaphragm inspection: 12 months or 5M cycles
- Coil resistance test: 24 months (≥85% of initial value)
| Property | Property Value |
|---|---|
| sku | 2L03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
