Airtac 2L Solenoid Valve 2L03008AI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03008AI Technical Details
- Model: 2L03008AI
- Type: 3-position 5-way double solenoid (closed center)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.8
- Response time: ≤30ms (exhaust to actuation)
- Weight: 300g ±5% (with connectors)
- Dimensions: 55mm(L) × 45mm(W) × 75mm(H)
- Seal material: Heat-resistant FKM fluorocarbon rubber
- Temperature range: -10℃ to 80℃ (150℃ peak for ≤5 mins)
- Power consumption: 2.5W (DC)/4.5VA (AC)
- Protection class: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A with LED indicator
- Max cycling rate: 5Hz (300 cycles/minute)
High-precision mid-flow directional control valve featuring dual-coil latching design for energy-efficient operation. The aluminum alloy body with hard anodized finish ensures corrosion resistance in humid environments. Integrated surge suppression protects against voltage spikes. Requires ISO 8573-1:2010 Class 3 lubricated or non-lubricated air.
- Multi-station pneumatic fixture sequencing
- Textile machinery shuttle control systems
- Bottle cap torque testing equipment
- Semiconductor wafer handling robots
- Automotive brake component assembly lines
Installation guidelines:
Mount with M4 screws (max torque 1.2N·m). Maintain ≥15mm clearance
below valve for tubing connections. Use shielded cables for EMI-sensitive
environments. Perform monthly manual override testing.
Do NOT use with oxygen/nitrogen
media above 0.5MPa. Maximum permissible humidity: 95% RH non-condensing.
Install downstream filter (5μm) when used with abrasive particulates.
| Property | Property Value |
|---|---|
| sku | 2L03008AI |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC220V |
