Airtac 2L Solenoid Valve 2L03008C
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03008C Technical Specifications
- Model: 2L03008C
- Type: 5/2-way single solenoid controlled (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V, DC24V, AC110V(50/60Hz), AC220V(50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 320g ±5% (including coil and accessories)
- Dimensions: 60mm(L) × 40mm(W) × 82mm(H)
- Flow coefficient (Cv): 1.8
- Seal material: HNBR rubber (high nitrile variant for oil resistance)
- Temperature range: -5℃ to 60℃ (fluid/ambient)
- Power consumption: 2.5W (DC)/5VA (AC)
- Response time: ≤15ms (open), ≤10ms (close)
- Protection grade: IP65 (coil)/IP40 (valve body)
- Port thread depth: 12mm (full thread engagement required)
High-flow directional control valve with manual override, featuring optimized spool geometry for reduced pressure drop. The aluminum alloy body with hard anodized finish provides enhanced corrosion resistance in humid environments. Compatible with ISO 15407-1 standards for industrial valve mounting interfaces.
- Pneumatic cylinder sequencing in automated assembly lines
- Clamping control for CNC machining centers
- Air circuit switching in offset printing machinery
- Packaging machine pneumatic actuators (vertical form-fill-seal units)
- Plastic injection molding machine ejector systems
Installation guidelines:
Mount with M5 screws (max torque 1.2N·m). Maintain ≥15mm clearance
from adjacent components for heat dissipation. Use air dryer to maintain
dew point 15℃ below ambient temperature. Lubricate with ISO VG32
turbine oil if operating below 0℃.
| Property | Property Value |
|---|---|
| sku | 2L03008C |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC 110V |
