Airtac 2L Solenoid Valve 2L05010B
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L05010B 5/2-Way Solenoid Valve Technical Details
- Model: 2L05010B (2L series)
- Valve type: 5/2-way, double solenoid operated
- Port configuration: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 420g ±5% (without connector)
- Dimensions: 58mm(L) × 40mm(W) × 78mm(H)
- Seal materials: HNBR (Hydrogenated Nitrile) for enhanced chemical resistance
- Temperature tolerance: -5℃ to 80℃ (no freeze)
- Flow capacity: 850 l/min (ANR)
- Response time: ≤15ms (at 0.5MPa)
- Protection class: IP67 (dustproof & temporary immersion resistant)
- Port thread depth: 12mm
High-flow directional control valve with dual coil configuration for precise bi-directional actuator control. Features corrosion-resistant aluminum alloy body with hard anodized finish. Designed for applications requiring rapid cycling (up to 5Hz) and stable performance in humid environments. Requires ISO 8573-1:2010 Class 3 compressed air quality.
- Pneumatic cylinder sequencing in assembly lines
- Rotary actuator control for material handling systems
- Textile machinery double-acting cylinder operations
- Plastic injection molding machine clamp units
- Automated warehouse stacker cranes
Installation guidelines:
Mount with 15mm minimum clearance on sides for heat dissipation. Use M5 mounting screws with 0.49-0.64N·m torque.
Always install downstream filter regulator (F.R.L. unit) with ≤25μm filtration.
Critical note:
Manual override requires 3.5N·m maximum rotational force. Do not apply lubricants incompatible with HNBR seals.
| Property | Property Value |
|---|---|
| sku | 2L05010B |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
