Airtac 2L Solenoid Valve 2L05010C
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L05010C Solenoid Valve Specifications
- Model: 2L05010C
- Type: 5/2-way double solenoid (dual coil) with spring return
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Flow capacity: 850 l/min (ANR) at 0.5 MPa
- Weight: 0.3 kg (including coils)
- Dimensions: 60mm(L) × 50mm(W) × 30mm(H)
- Seal material: Heat-resistant NBR (Nitrile) with anti-stick additives
- Temperature range: -5℃ to 80℃ (non-freezing conditions)
- Power consumption: 1.6W (DC) / 3.2VA (AC)
- Response time: ≤15ms (exhaust to full actuation)
- Protection rating: IP67 (coils), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-speed 5-port directional valve featuring twin independent coils for precise bi-directional control. Enhanced dust/water resistance through multi-layered sealing architecture. The hardened aluminum body with anodized treatment ensures durability in high-cycle industrial environments (＞10 million operations). Requires 5μm filtered air with oil mist lubrication recommended.
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery shuttle control systems
- Automated welding equipment clamp positioning
- Bottle capping machine actuator control
- Plastic injection molding ejector mechanisms
Installation protocol:
Mount with M5 screws (max torque 1.2N·m). Maintain 15mm clearance
below valve for condensate drainage. Always install silencers
on exhaust ports (Rc1/8) to prevent backflow contamination.
Critical note:
Coils must NOT be energized continuously for >2 minutes -
use pulse-width modulation (PWM) control for sustained operation
to prevent overheating.
| Property | Property Value |
|---|---|
| sku | 2L05010C |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC 110V |
