Airtac 2LH Fluid Solenoid Valve 2LH03006-X0
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03006-X0 Fluid Solenoid Valve Specifications
- Model: 2LH03006-X0
- Type: 2-position, 3-way normally closed (direct-acting)
- Fluid compatibility: Water, light oil, air (non-corrosive fluids)
- Port size: PT1/4 (BSPP thread)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Flow rate: 12 L/min at 0.5 MPa (water)
- Response time: ≤15ms (excitation), ≤20ms (de-energization)
- Seal material: EPDM (standard), optional FKM/Viton®
- Temperature range: -5℃ to 80℃ (fluid/media)
- Ambient temperature: -20℃ to 50℃
- Power consumption: 2.8W (DC), 3.5VA (AC)
- Protection rating: IP67 (coil protection)
- Port alignment: 3/8"-24 UNF ports on 18mm centers
- Weight: 220g ±5% (excluding connector)
- Dimensions: 50mm(L) × 34mm(W) × 72mm(H)
High-flow fluid control valve with integrated manual override, designed for precise liquid media regulation in corrosive environments. Features lead-wire type connection (250mm PVC cable standard) and corrosion-resistant brass body with electroless nickel plating. Compatible with pulse-width modulation (PWM) control systems.
- Industrial dishwasher water control systems
- Automated irrigation and fertigation systems
- Medical equipment fluid circuits
- Beverage dispensing machines
- Coolant control in CNC machinery
- Hydroponic nutrient delivery systems
Installation guidelines:
Mount with flow direction arrow aligned. Install 100-mesh upstream filter.
For vertical installation, position coil upward. Bleed air from system
after installation. Lubricate seals with water-soluble lubricant if used
with viscous fluids.
| Property | Property Value |
|---|---|
| sku | 2LH03006-X0 |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
