Airtac 2LH Fluid Solenoid Valve 2LH03006BI
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03006BI Fluid Solenoid Valve Specifications
- Model: 2LH03006BI
- Type: 2-position, 5-way direct-acting (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 L/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Weight: 680g ±2% (including connectors)
- Dimensions: 67mm(L) × 45mm(W) × 89mm(H) (excluding mounting brackets)
- Seal materials: HNBR main seals with FKM backup rings
- Temperature tolerance: -10℃ to 80℃ (with intermittent operation up to 100℃ for ≤15 mins)
- Power consumption: 4.5W (DC models), 5.2VA (AC models)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow bidirectional control valve featuring dual-coil latching design for energy-efficient operation. The aluminum alloy body with hard anodized coating ensures corrosion resistance in humid environments. Includes manual override and LED status indicator. Requires 5μm filtered air with oil mist lubrication (ISO VG32 recommended).
- Automated assembly line cylinder sequencing
- Beverage filling machine pneumatic circuits
- Plastic injection molding machine clamp control
- Wastewater treatment plant valve actuators
- Semiconductor wafer handling robotics
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 50mm clearance below valve for heat dissipation.
Use thread sealant (Loctite 545 recommended) for metal-to-metal connections.
| Property | Property Value |
|---|---|
| sku | 2LH03006BI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
