Airtac 2LH Fluid Solenoid Valve 2LH03006E
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03006E Fluid Solenoid Valve Technical Details
- Model: 2LH03006E
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Flow capacity: 800 l/min (Cv=1.3)
- Operating pressure: 0.1–1.0 MPa
- Voltage variants: DC12V(±10%), DC24V(±10%), AC110V(±10% 50/60Hz), AC220V(±10% 50/60Hz)
- Body material: Reinforced PBT resin with fiberglass
- Seal material: FKM (Viton) for chemical resistance
- Weight: 320g ±5%
- Dimensions: 54mm(L) × 40mm(W) × 72mm(H) (excluding connectors)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Power consumption: 2.8W (DC), 3.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (4 full threads minimum engagement)
High-flow compact solenoid valve featuring corrosion-resistant construction and rapid switching capability. The dual-chamber design prevents fluid mixing, with a self-cleaning spool mechanism that maintains performance in viscous fluids. Requires 25μm filtration for optimal operation. Compatible with water, light oils, and neutral gases (non-lubricated air requires optional seal kit).
- Beverage dispensing systems (sanitary liquid control)
- Coolant flow management in CNC machining centers
- Water treatment plant chemical dosing
- Pharmaceutical production line solvent control
- Semiconductor wafer cleaning equipment
- Hydroponic irrigation systems
Installation guidelines:
Mount horizontally with arrow aligned to flow direction. Use flexible tubing
connectors to absorb vibration. Perform monthly manual cycling during standby
periods to prevent spool sticking. Maximum allowable ambient humidity: 85% RH.
| Property | Property Value |
|---|---|
| sku | 2LH03006E |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
