Airtac 2LH Fluid Solenoid Valve 2LH03006EI
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03006EI Fluid Solenoid Valve Technical Details
- Model: 2LH03006EI
- Valve type: 5/2-way direct acting (double solenoid)
- Port size: G3/8 (BSPP thread)
- Operating pressure: 0.1–1.0 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 2.3VA (AC)
- Flow coefficient (Cv): 1.2
- Response time: ≤30ms (exhaust to actuation)
- Seal material: Heat-resistant NBR (Nitrile) / Optional FKM (Fluorocarbon)
- Temperature range: -5℃ to 80℃ (NBR), -10℃ to 150℃ (FKM)
- Weight: 530g ±5% (without connectors)
- Dimensions: 102mm(L) × 52mm(W) × 64mm(H)
- Protection class: IP67 (dust/water resistant)
- Port alignment: ISO 5599-1 standard
High-flow bidirectional solenoid valve engineered for aggressive duty cycles in industrial automation. Features dual manual override buttons, LED status indicators, and surge protection circuitry. The aluminum alloy body with hard anodized coating ensures corrosion resistance in humid environments. Requires 5μm filtration for optimal performance.
- Pneumatic cylinder sequencing in assembly lines
- Bottle filling machine pressure regulation
- Wastewater treatment plant valve clusters
- Automotive paint shop actuators
- Semiconductor cleanroom equipment
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Lubricate seals with ISO VG32 hydraulic oil during maintenance.
Allow 15mm side clearance for electrical connector access.
| Property | Property Value |
|---|---|
| sku | 2LH03006EI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
