Airtac 2LH Fluid Solenoid Valve 2LH03008A
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03008A Fluid Solenoid Valve Technical Specifications
- Model: 2LH03008A
- Type: 2-position, 3-way direct-acting solenoid valve (Normally Closed)
- Port size: PT3/8 (G3/8 thread standard)
- Operating pressure: 0.05–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Fluid compatibility: Air, water, light oils (ISO VG32 or lower)
- Flow coefficient (Cv): 0.65
- Response time: ≤15ms (open), ≤10ms (close)
- Seal material: High-grade NBR (Nitrile rubber)
- Body material: Aluminum alloy (anodized surface)
- Ambient temperature: -10℃ to 80℃
- Fluid temperature: 0℃ to 60℃
- Protection class: IP67 (dustproof & temporary immersion protection)
- Electrical connection: DIN43650 Form A connector
- Weight: 340g ±5g
- Dimensions: 62mm(L) × 42mm(W) × 85mm(H)
- Power consumption: ≤2.5W (DC), ≤3.5VA (AC)
High-flow compact solenoid valve with pressure-balanced poppet design, featuring zero-pressure start capability and surge protection circuitry. The hardened stainless steel plunger and military-grade coil insulation ensure 500,000+ cycle durability. Requires 25μm filtration for optimal performance.
- Pneumatic cylinder control in automated assembly lines
- Coolant flow management in CNC machining centers
- Water circulation systems for food processing equipment
- Vacuum pump control in packaging machinery
- Medical sterilization device fluid control
Installation guidelines:
Mount in vibration-free environment with flow arrow aligned.
For horizontal mounting, use optional bracket (accessory code: BR-2LH).
Perform monthly manual override tests using side-mounted emergency actuator.
Critical note:
Not compatible with glycol-based fluids or abrasive media.
Minimum 500-hour maintenance interval required when used with oil mist lubrication systems.
| Property | Property Value |
|---|---|
| sku | 2LH03008A |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
