Airtac 2LH Fluid Solenoid Valve 2LH03008AI
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03008AI Fluid Solenoid Valve Technical Details
- Model: 2LH03008AI
- Type: 2-position 5-port direct-acting/pilot-operated
- Port configuration: 5/2-way
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V/220V 50/60Hz
- Flow capacity: 1200 Nl/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 0.85 kg (1.87 lbs)
- Dimensions: 105mm(L) × 54mm(W) × 44mm(H)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: 2.2W (DC), 4.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Cycle life: ≥10 million operations
High-flow solenoid valve with double electrical connection design for stable performance in continuous operation. Features corrosion-resistant aluminum alloy body with anodized surface treatment and gold-plated terminals for enhanced conductivity. The optimized spool structure reduces air consumption by 15% compared to previous generations. Requires 5μm filtered compressed air with oil mist lubrication (ISO 8573-1 class 4).
- Automated production line cylinder control
- Textile machinery pneumatic systems
- Plastic injection molding machines
- Semiconductor manufacturing equipment
- Automotive brake testing systems
- Food-grade pneumatic actuators (certified for incidental contact)
Installation guidelines:
Mount in vibration-free environment with arrow alignment to airflow direction.
Maintain 0.5-1 bar higher pilot pressure than working pressure.
Lubricate every 6 months using ISO VG32 turbine oil.
Avoid lateral piping stress on valve ports.
| Property | Property Value |
|---|---|
| sku | 2LH03008AI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
