Airtac 2LH Fluid Solenoid Valve 2LH03008BI
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03008BI Fluid Solenoid Valve Specifications
- Model: 2LH03008BI
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G1/8 (BSPP thread)
- Fluid compatibility: Water, oil, neutral gases (non-corrosive media)
- Operating pressure: 0.02–0.8 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC24V (±10%), AC110V (±15%), AC220V (±15%)
- Power consumption: DC: 2.4W max | AC: 3.2VA max
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: FKM (Viton® equivalent) for chemical resistance
- Temperature range: -5℃ to 80℃ (fluid temp), -20℃ to 50℃ (ambient)
- Protection rating: IP67 (dustproof & temporary immersion protection)
- Weight: 310g ±5g
- Dimensions: 52mm(L) × 26mm(W) × 75mm(H) (excluding connectors)
- Port thread depth: 12mm (male thread)
- Max flow rate: 15L/min (water at 0.5MPa)
- Cycle rate: ≤5Hz (300 cycles/minute)
High-precision fluid control valve with direct-acting mechanism, featuring corrosion-resistant brass body and chemically inert seals. Designed for precise liquid/gas flow regulation in critical applications. Requires 25μm filtration upstream. Includes manual override button for system diagnostics.
- Medical device fluid control systems
- Food processing equipment liquid dispensing
- Photochemical etching machines
- Hydroponic nutrient delivery systems
- Industrial coolant circulation control
- Beverage filling line flow regulation
Installation guidelines:
Mount in horizontal orientation with coil facing upward. Install drip-proof cover (optional ACC-02A) in humid environments.
Allow 20mm clearance below valve for drain access. Use PTFE tape on threads with clockwise wrap direction.
| Property | Property Value |
|---|---|
| sku | 2LH03008BI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
