Airtac 2LH Fluid Solenoid Valve 2LH03008E
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03008E Fluid Solenoid Valve Technical Specifications
- Model: 2LH03008E
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G1/8 (BSPP thread)
- Port configuration: IN/OUT/EXH
- Operating medium: Compressed air, inert gases, water (non-corrosive fluids)
- Pressure range: 0.05–1.0 MPa
- Flow coefficient (Cv): 0.6
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.5W / AC: 3.2VA
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced chemical resistance
- Temperature range:
- Ambient: -20℃ to 60℃
- Medium: 0℃ to 60℃ (water), -20℃ to 60℃ (air)
- Protection rating: IP67 (dustproof and temporary immersion protection)
- Weight: 280g ±5g (with coil)
- Dimensions: 58mm(L) × 34mm(W) × 48mm(H)
- Mounting orientation: Any (horizontal recommended for liquid applications)
- Expected service life: ≥10 million cycles (at rated conditions)
High-performance general-purpose solenoid valve featuring low-hysteresis operation and zero pressure differential start capability. The brass body with electroless nickel plating provides corrosion resistance, while the encapsulated coil design prevents moisture ingress. Compatible with both pneumatic and hydraulic systems when using appropriate seals.
- Industrial coolant flow control in CNC machines
- Dispensing systems for adhesives/solvents
- Water treatment plant pneumatic actuators
- Beverage filling line liquid control
- Laboratory analytical instrument gas switching
Installation guidelines:
For liquid applications, install downstream filter (25μm minimum).
Maintain 30mm clearance around coil for heat dissipation.
Use thread sealant on male ports (PTFE tape not recommended).
Cycle testing recommended before permanent installation.
| Property | Property Value |
|---|---|
| sku | 2LH03008E |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
