Airtac 2LH Fluid Solenoid Valve 2LH03008F
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03008F Fluid Solenoid Valve Technical Details
- Model: 2LH03008F
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: PT1/4 (G1/8 optional)
- Fluid compatibility: Air, water, light oils (ISO VG32 or below)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Weight: 300g ±5% (excluding connector)
- Dimensions: 80mm(L) × 42mm(W) × 50mm(H)
- Seal material: NBR (standard), FKM available for high-temp variants
- Temperature range: -5℃ to 80℃ (NBR seals), -10℃ to 150℃ with FKM seals
- Response time: ≤15ms (at 0.5MPa)
- Flow coefficient (Cv): 1.2 (Kv=1.0)
- Protection rating: IP67 (coil assembly), IP54 (entire unit)
- Electrical connection: DIN43650 Form A (standard), optional lead wire
High-flow compact solenoid valve with brass body and reinforced nylon components. Features manual override button for system debugging and emergency operation. The optimized magnetic circuit design ensures stable performance under voltage fluctuations (±10% tolerance). Compatible with both liquid and gaseous media when using appropriate seals.
- Food processing equipment coolant control
- Pharmaceutical CIP (Clean-in-Place) systems
- Water treatment plant dosing systems
- Industrial dishwasher fluid circuits
- Low-viscosity lubricant distribution systems
Installation guidelines:
Maintain horizontal piping orientation for liquid applications. Install upstream
25μm filter for media containing particulates. When using with water, ensure
complete drainage during winter shutdowns to prevent freezing damage.
| Property | Property Value |
|---|---|
| sku | 2LH03008F |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
