Airtac 2LH Fluid Solenoid Valve 2LH05010A
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH05010A Fluid Solenoid Valve Technical Details
- Model: 2LH05010A
- Type: 2-position, 5-way direct-acting (universal porting)
- Port size: G1/8 (BSPP) with ISO standard flange
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 280g ±5% (with coil)
- Dimensions: 58mm(L) × 46mm(W) × 52mm(H)
- Seal material: FKM (Viton) standard, optional EPDM/NBR
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Flow rate: 650 NL/min (ANR, at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 9.5mm (minimum engagement)
High-flow proportional control valve with metal seal options for aggressive media. Features dual-position memory function and surge protection circuitry. Optimized for vacuum/pressure switching applications with 100% ED (continuous duty) capability. Requires 25μm filtration with oil mist lubrication (ISO 8573-1 class 4).
- Plastic injection molding machine clamp controls
- Semiconductor wafer handling vacuum systems
- Automated liquid dispensing equipment
- Beverage filling line pneumatic actuators
- Lithium battery production dry room environments
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain ≥15mm clearance from adjacent components for heat dissipation.
Use Loctite 545 thread sealant (not PTFE tape) for port connections.
| Property | Property Value |
|---|---|
| sku | 2LH05010A |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
