Airtac 2LH Fluid Solenoid Valve 2LH05010AI
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH05010AI Fluid Solenoid Valve Technical Details
- Model: 2LH05010AI
- Type: 5/2-way direct-acting solenoid valve (double coil)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Weight: 450g ±5% (with coils installed)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 120℃ (fluid/ambient)
- Power consumption: ≤5W (AC), ≤4.5W (DC)
- Protection rating: IP67 (coils), IP40 (valve body)
- Flow coefficient (Cv): 1.8
- Response time: ≤30ms (energize), ≤50ms (de-energize)
High-flow proportional control valve with double coil latching design, featuring stainless steel plunger and reinforced nylon body. Engineered for aggressive media control with 500,000+ cycle durability. Requires filtered compressed air or neutral gases (ISO 8573-1 class 3). Compatible with vacuum applications down to -95kPa.
- Plastic injection molding machine cylinder control
- Food processing pneumatic actuators (FDA-compliant versions available)
- Chemical dosing systems with corrosive media
- Automated packaging line diverters
- Semiconductor manufacturing vacuum handling
Installation guidelines:
Mount horizontally with manifold brackets (M5 thread). Use copper-free
piping compounds. For pulsation reduction, install 10cm downstream tubing
before actuators. Lubricate with ISO VG32 turbine oil if used with dry air.
| Property | Property Value |
|---|---|
| sku | 2LH05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
