Airtac 2LH Fluid Solenoid Valve 2LH05010BI
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH05010BI Fluid Solenoid Valve Technical Details
- Model: 2LH05010BI
- Type: 2-position, 5-port (5/2-way) pilot-operated
- Port size: G1/8 (BSPP thread)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 650 l/min (Cv=1.1 at 0.5MPa)
- Response time: ≤30ms (exhaust to actuation)
- Weight: 420g ±3% (including coil)
- Dimensions: 56mm(W) × 62mm(H) × 104mm(L)
- Seal materials: FKM (fluorocarbon) main seals, NBR auxiliary seals
- Temperature range: -5℃ to 80℃ (with intermittent peaks to 100℃ for ≤10 mins)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (full engagement recommended)
High-flow proportional control valve with corrosion-resistant aluminum alloy body and dual-pressure operation capability. Features manual override button for system debugging and emergency control. The low-hysteresis design maintains precise flow regulation even with rapid cycling (up to 5Hz operation). Compatible with ISO 8573-1:2010 [3:4:3] class compressed air.
- Pneumatic cylinder sequencing in assembly line automation
- Vacuum pump control systems
- Coolant flow regulation in CNC machining centers
- Beverage filling equipment pressure balancing
- Wastewater treatment plant pneumatic actuators
Maintenance advisory:
Lubricate pilot valve stem quarterly with ISO VG32 turbine oil.
Install downstream moisture trap when used in high-humidity environments (>80% RH).
- Max vibration tolerance: 2.5G at 10-150Hz
- Recommended torque: 12-15N·m for port connections
- Orientation: Any, but vertical mounting extends seal life
| Property | Property Value |
|---|---|
| sku | 2LH05010BI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
