Airtac 2LH Fluid Solenoid Valve 2LH05010E
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH05010E Fluid Solenoid Valve Specifications
- Model: 2LH05010E
- Type: 5/2-way direct-acting with manual override
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 850 L/min (ANR)
- Response time: ≤15ms (at 0.5MPa)
- Weight: 0.25kg ±5%
- Dimensions: 67mm(L) × 44mm(W) × 42mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: Heat-resistant FKM fluorocarbon rubber
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 13mm (full thread engagement recommended)
High-flow bidirectional solenoid valve with positive pressure operation, featuring integrated silencer and status indicator LED. The hardened stainless steel plunger ensures 5-million-cycle durability. Compatible with compressed air and inert gases (N2/CO2). Requires 25μm filtration and ISO 8573-1:2010 Class 3 air quality.
- Automated production line cylinder control
- Beverage filling machine actuators
- Textile machinery air circuit switching
- Plastic injection molding ejection systems
- Semiconductor cleanroom equipment
Installation note:
Mount in vibration-free environment using M4 mounting screws (max torque 1.2N·m).
Lubricate with ISO VG32 turbine oil if used in continuous duty cycles above 60℃.
| Property | Property Value |
|---|---|
| sku | 2LH05010E |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
