Airtac 2LH Fluid Solenoid Valve 2LH05010F
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH05010F Fluid Solenoid Valve Specifications
- Model: 2LH05010F
- Type: 2-position, 2-way normally closed (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.8 MPa
- Max working pressure: 1.0 MPa
- Voltage options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Power consumption: 2.8W (DC) / 4.5VA (AC)
- Flow coefficient (Cv): 0.7
- Response time: ≤15ms
- Seal material: FKM (Fluorocarbon Rubber)
- Body material: Brass with nickel plating
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Protection rating: IP67 (NEMA 4 equivalent)
- Weight: 215g ±5g
- Dimensions: 60mm(L) × 45mm(W) × 36mm(H)
- Port thread depth: 12mm
High-flow fluid control valve with enhanced corrosion resistance, featuring dual-chamber structure for stable operation with viscous liquids. Rated for continuous duty cycle with epoxy-encapsulated coil. Compatible with water, light oils, and neutral gases. Requires 50μm filtration and vertical installation orientation.
- Industrial water treatment systems
- Chemical dosing equipment
- Beverage dispensing machines
- Coolant control in CNC machinery
- Hydroponic irrigation systems
- Medical sterilization equipment
Installation note:
Always install downstream filter (minimum 50μm). For viscous fluids,
preheat to ≤40℃ before system startup. Manual override available
via push-button actuator (requires 3mm tool access).
| Property | Property Value |
|---|---|
| sku | 2LH05010F |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
