Airtac 2S Fluid Control Valve 2S05015A
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05015A Fluid Control Valve Specifications
- Model: 2S05015A
- Type: 3-position, 5-port closed center (pneumatic pilot operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (customizable)
- Weight: 320g ±5g
- Dimensions: 58mm(L) × 40mm(W) × 34mm(H)
- Seal material: NBR (nitrile) standard, FKM (fluorocarbon) optional
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Flow coefficient (Cv): 1.2
- Response time: ≤50ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
- Max operating frequency: 5Hz
High-precision directional control valve with center-block function, featuring dual-pressure pilot operation for reliable switching. The anodized aluminum body ensures corrosion resistance in humid environments. Designed for systems requiring intermediate position pressure holding, with optimized flow paths reducing pressure drop by 15% compared to previous generations.
- Industrial robotic gripper pressure regulation
- CNC machine tool clamping sequences
- Plastic injection molding machine actuators
- Automated assembly line positioning systems
- Test bench pressure cycling equipment
Installation note:
Mount in vibration-free locations using M4 mounting screws (not included).
Maintain 0.5-1.0mm clearance between manifold surfaces during bank mounting.
Lubricate seals with ISO VG32 turbine oil before initial use.
| Property | Property Value |
|---|---|
| sku | 2S05015A |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
