Airtac 2S Fluid Control Valve 2S05015AI
$58.12
Regular price
$65.62
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2S05015AI
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、2-position, 2-way solenoid valve with piston pilot normally closed configuration, featuring rapid switching and high flow capacity;
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
Installation guidelines:
Use with 5μm filtered dry air. Allow 15mm clearance below valve for tubing routing.
Apply thread sealant only on male ports (tapered threads). Cycle test 3x before full load operation.
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05015AI Fluid Control Valve Technical Details
- Model: 2S05015AI
- Type: 5-port/3-position closed center (Double solenoid)
- Port size: G1/8 (ISO standard)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 L/min (ANR)
- Response time: ≤30ms (exhaust to actuation)
- Weight: 340g ±5% (with connectors)
- Dimensions: 82mm(L) × 48mm(W) × 63mm(H)
- Valve body material: Reinforced PBT (UL94 V-0 rated)
- Seal material: Heat-resistant NBR (-20℃ to 120℃)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
- Mounting: ISO 15407-1 compliant sub-base
High-flow directional control valve with dual coil redundancy, featuring zero-pressure differential operation capability. The encapsulated coil design prevents fluid ingress during washdown environments. Includes manual override and position indicator for maintenance diagnostics.
Industrial Applications:
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Food processing pneumatic circuits (NSF compliant)
- Battery production handling equipment
- Textile machinery tension control systems
Installation guidelines:
Use with 5μm filtered dry air. Allow 15mm clearance below valve for tubing routing.
Apply thread sealant only on male ports (tapered threads). Cycle test 3x before full load operation.
Service life:
10 million cycles (minimum) under rated conditions. Replace seals every 2 years in continuous operation.
Coil resistance tolerance: ±15% at 20℃ ambient.
| Property | Property Value |
|---|---|
| sku | 2S05015AI |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
