Airtac 2S Fluid Control Valve 2S05015FI
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S Series Fluid Control Valve 2S05015FI Technical Details
- Model: 2S05015FI
- Type: 2-position 5-port direct-acting solenoid valve
- Port configuration: 5/3-way (closed center)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 L/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 620g ±5% (including coil)
- Dimensions: 60mm(L) × 50mm(W) × 95mm(H)
- Seal materials: HNBR/Nitrile compound (standard), optional FKM for chemical resistance
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Power consumption: 3.5W (DC), 4.5VA (AC)
- Protection class: IP67 (coil), IP40 (valve body)
- Port alignment: ISO 5599-1 standard (compliant with CETOP RP52P)
High-flow proportional control valve engineered for precision fluid regulation in industrial automation systems. Features low-hysteresis spool design with copper-free aluminum alloy construction, achieving 10 million cycle durability. The integrated LED status indicator and manual override facilitate maintenance diagnostics. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Plastic injection molding machine sequence control
- Beverage filling line pressure regulation
- Semiconductor wafer handling robotics
- Textile machinery pneumatic circuits
- Automotive assembly line clamping systems
Installation protocol:
Mount with vibration-damping brackets in environments exceeding 0.5G vibration.
Maintain 20mm clearance below valve for condensate drainage. Lubricate using ISO VG32
turbine oil if operating below 0℃.
| Property | Property Value |
|---|---|
| sku | 2S05015FI |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC12V |
