Airtac 2S Fluid Control Valve 2S15015AI
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S15015AI Fluid Control Valve Technical Details
- Model: 2S15015AI
- Type: 5/3-way closed center, solenoid pilot-operated
- Port size: G1/2 (NPT1/2 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 1.2 kg (2.65 lbs) ±5%
- Dimensions: 100mm(L) × 60mm(W) × 45mm(H)
- Seal materials: FKM (fluorocarbon rubber) standard, EPDM optional
- Fluid temperature range: -10℃ to 80℃ (14°F to 176°F)
- Flow capacity: Cv=3.2 (at 7 bar)
- Response time: ≤20ms (energize), ≤15ms (de-energize)
- Protection class: IP67 (dustproof and temporary immersion resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with triple-position functionality, engineered for precise directional control in hydraulic/pneumatic hybrid systems. Features hardened aluminum alloy body with anti-vibration mounting points and gold-plated connectors for corrosion resistance. Requires 25μm filtration and automatic drain installation in high-humidity environments.
- Industrial automation sequencing circuits
- Beverage filling line pressure modulation
- Hydraulic press mid-stroke position holding
- Wastewater treatment plant pneumatic actuators
- Automotive assembly line clamping systems
Installation protocol:
Mount with vibration-damping washers on horizontal surfaces only.
Maintain 15mm clearance below valve for condensate drainage.
Lubricate seals with ISO VG32 hydraulic oil during maintenance.
| Property | Property Value |
|---|---|
| sku | 2S15015AI |
| Port Size | PT 1/2 |
| Flow Aperture | <15mm> |
| Coil Voltage | AC220V |
