Airtac 2S Fluid Control Valve 2S15015AIG
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S Series Fluid Control Valve 2S15015AIG Technical Details
- Model: 2S15015AIG
- Type: 5/3-way closed center (double solenoid)
- Port configuration: 15mm ISO G1/4 BSPP threaded ports
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Maximum flow rate: 1,200 NL/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 1.65 kg (3.64 lbs) ±5%
- Dimensions: 144mm(L) × 52mm(W) × 88mm(H)
- Seal materials: HNBR (Hydrogenated Nitrile) with PTFE backup rings
- Temperature tolerance: -10℃ to 80℃ (non-freezing conditions)
- Response time: ≤30ms (energize), ≤20ms (de-energize)
- Protection standard: IP67 (dust tight & temporary immersion)
- Mounting orientation: Any (horizontal/vertical)
High-flow directional control valve with zero leakage design, featuring brass alloy body with chrome-plated spool for smooth operation. The dual solenoid configuration enables precise mid-position shutoff control. Requires 5μm filtration (with auto-drain) and lubricated air (ISO VG32 equivalent). Includes manual override and surge suppression circuitry.
- Plastic injection molding machine clamp controls
- Automated assembly line actuator sequencing
- Die casting machine hydraulic-pneumatic interfaces
- Test bench pressure cycling systems
- Food processing vacuum/pressure chambers
Maintenance protocol:
Perform quarterly spool lubrication with ISO VG32 oil mist (1-2 drops).
Avoid rapid pressure fluctuations >0.3 MPa/sec to prevent seat damage.
Critical note:
Not compatible with phosphate ester fluids or ammonia-based lubricants.
Minimum 20mm clearance required below valve for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2S15015AIG |
| Port Size | PT 1/2 |
| Flow Aperture | <15mm> |
| Coil Voltage | AC220V |
