Airtac 2S Fluid Control Valve 2S15015AT
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S15015AT Fluid Control Valve Specifications
- Model: 2S15015AT
- Type: 5/3-way closed center (Double solenoid pilot-operated)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.2–1.0 MPa
- Max flow capacity: 1,800 Nl/min (ANR)
- Voltage options: DC24V (±10%), AC110V/220V (±15% 50/60Hz)
- Weight: 1.65 kg ±2%
- Dimensions: 145mm(L) × 52mm(W) × 92mm(H)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -10℃ to 80℃ (with anti-freeze measures)
- Power consumption: 4.5W (DC), 6VA (AC)
- Response time: ≤50ms (exhaust to center position)
- Protection rating: IP67 (dust/water resistant)
- Endurance: ≥5 million cycles
High-flow directional control valve with center-block function, featuring dual electromagnetic control for precise mid-position holding. The aluminum alloy body with hard anodized surface treatment ensures corrosion resistance in humid environments. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Hydraulic press clamping sequence control
- Plastic injection molding machine actuators
- Automated assembly line positioning systems
- Textile machinery tension control
- Bottle blowing machine air circuits
Installation note:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15mm clearance below valve for condensate drainage.
Use M5x12 mounting screws (torque ≤1.2N·m).
| Property | Property Value |
|---|---|
| sku | 2S15015AT |
| Port Size | PT 1/2 |
| Flow Aperture | <15mm> |
| Coil Voltage | AC220V |
