Airtac 2SH High Pressure Solenoid Valve 2SH03006C
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH03006C High Pressure Solenoid Valve Specifications
- Model: 2SH03006C
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.5–12 MPa (72–1740 psi)
- Max working pressure: 16 MPa (2320 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 3.8W (DC), 5.5VA (AC)
- Flow coefficient (Cv): 0.14
- Response time: ≤15ms (open/close)
- Seal material: Fluororubber (FKM) standard (NBR optional)
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Protection rating: IP67 (dustproof & waterproof)
- Electrical connection: DIN43650 Form A
- Weight: 320g ±5%
- Dimensions: 58mm(L) × 34mm(W) × 47mm(H)
- Port thread depth: 12mm
Heavy-duty high-pressure solenoid valve engineered for industrial hydraulic and pneumatic systems requiring extreme pressure handling. Features brass body with hard chrome-plated stainless steel core tube for enhanced durability. Includes manual override button for system testing/diagnostics. Compatible with air, water, and light hydraulic oils (ISO VG32 or lower). Requires 25μm filtration.
- Hydraulic press emergency stop circuits
- High-pressure water jet cutting systems
- CNC machine tool coolant control
- Plastic injection molding machines
- Test bench pressure regulation systems
- Construction equipment pneumatic controls
Installation requirements:
Mount in vibration-free environment using supplied bracket.
For vertical installation, orient coil upward.
Always install downstream moisture separator when used with compressed air.
Maintenance note:
Replace seals every 500,000 cycles or 2 years (whichever comes first)
when operating above 8 MPa. Use only AirTAC-approved lubricants.
| Property | Property Value |
|---|---|
| sku | 2SH03006C |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
