Airtac 2SH High Pressure Solenoid Valve 2SH03006F
$45.35
Regular price
$52.85
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2SH03006F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The 2SH High-Pressure Solenoid Valve features:
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
Installation protocol:
Perform pressure decay test (≤0.1MPa/min leakage rate) before commissioning.
Use anti-vibration mounts in applications exceeding 10Hz mechanical frequency.
Replace seals every 8,000 operating hours under continuous high-pressure conditions.
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH03006F High-Pressure Solenoid Valve Specifications
- Model: 2SH03006F
- Type: 5/2-way direct-acting (high-pressure series)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.3–16 MPa (4.35–2320 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Weight: ~650g (including connectors)
- Dimensions: 120mm(L) × 50mm(W) × 55mm(H)
- Body material: Stainless steel SS304
- Seal material: FKM (Fluorocarbon rubber)
- Temperature range: -10℃ to 120℃ (non-freezing)
- Response time: ≤15ms (open), ≤10ms (close)
- Flow coefficient: CV 1.8 (Kv 2.06)
- Protection rating: IP67 (dustproof & waterproof)
- Port thread depth: 12mm (with O-ring seal)
Heavy-duty solenoid valve engineered for extreme pressure systems, featuring stainless steel construction and fluorine rubber seals. Equipped with manual override and surge protection circuitry. Requires 25μm filtration and lubrication-free air (NEMA Class IIB gas groups compatible).
Industrial Applications:
- Hydraulic pressurization systems
- Pneumatic punching/stamping machinery
- CNC machine tool clamping units
- Oil & gas pipeline control systems
- High-pressure test bench automation
Installation protocol:
Perform pressure decay test (≤0.1MPa/min leakage rate) before commissioning.
Use anti-vibration mounts in applications exceeding 10Hz mechanical frequency.
Replace seals every 8,000 operating hours under continuous high-pressure conditions.
| Property | Property Value |
|---|---|
| sku | 2SH03006F |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
