Airtac 2SH High Pressure Solenoid Valve 2SH03008B
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH03008B High-Pressure Solenoid Valve Specifications
- Model: 2SH03008B
- Type: 2-position 5-way pilot-operated (monostable)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.3–16 MPa (ultra-high pressure range)
- Max flow rate: 1800 NL/min (ANR)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 820g ±5% (including coil)
- Dimensions: 120mm(L) × 65mm(W) × 55mm(H)
- Seal material: FKM fluorocarbon rubber (oil/chemical resistant)
- Temperature range: -10℃ to 150℃ (ambient/fluid)
- Power consumption: ≤5W (DC)/≤6.5VA (AC)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Response time: ≤25ms (at 0.7MPa)
- Service life: ≥10 million cycles (under rated conditions)
Heavy-duty high-pressure solenoid valve engineered for industrial hydraulic/pneumatic systems requiring extreme pressure handling. Features dual-coil heat dissipation design with overvoltage protection circuitry. Requires ISO 8573-1 Class 3 compressed air (max 5mg/m³ oil content). Compatible with vacuum applications down to -100kPa.
- Injection molding machine hydraulic circuits
- Steel mill pneumatic conveying systems
- Hydraulic press accumulator controls
- Off-road vehicle braking systems
- High-pressure gas chromatography equipment
- Shipboard hydraulic winch operations
Installation protocol:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 50mm clearance on exhaust ports. Perform monthly
manual override tests for critical systems. Replace seals every
15,000 operating hours under continuous high-pressure use.
| Property | Property Value |
|---|---|
| sku | 2SH03008B |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
