Airtac 2SH High Pressure Solenoid Valve 2SH03008C
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH03008C High Pressure Solenoid Valve Specifications
- Model: 2SH03008C
- Type: 2-position, 5-way direct-acting (monostable)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.1–25 MPa (extended high-pressure design)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.85 kg ±5% (including coil)
- Dimensions: 120mm(L) × 48mm(W) × 62mm(H) (body only)
- Seal material: Fluorocarbon rubber (FKM) for high chemical resistance
- Temperature range: -10℃ to 150℃ (with high-temp coil option)
- Power consumption: 4.8W (DC), 5.5VA (AC)
- Flow coefficient (Cv): 2.1 (at 7 bar)
- Response time: ≤15ms (pressurized), ≤30ms (exhaust)
- Protection rating: IP67 (connector type: DIN43650 Form C)
- Port thread depth: 12mm (minimum engagement)
Industrial-grade high-pressure valve with stainless steel plunger system, designed for hydraulic and compressed gas systems requiring extreme pressure handling. Features double-sealing structure with hardened brass body and anti-vibration coil design. Requires 10μm filtration (25μm max) with oil mist lubrication recommended for continuous operation.
- Hydraulic press control circuits
- CNC machine tool clamping systems
- High-pressure gas chromatography equipment
- Plastic injection molding machines
- Industrial boiler safety venting systems
- Pressure testing rigs (up to 250 bar)
Installation note:
Requires horizontal mounting orientation with pressure port (P) facing downward.
Use copper crush washers (included) for port connections.
Minimum 30-minute run-in period recommended for initial seal seating.
| Property | Property Value |
|---|---|
| sku | 2SH03008C |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
