Airtac 2SH High Pressure Solenoid Valve 2SH05010A
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH05010A High-Pressure Solenoid Valve Specifications
- Model: 2SH05010A
- Type: 2-position, 5-port direct-acting (monostable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.3–16 MPa (industry-leading high-pressure capacity)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 1200 Nl/min (ANR) at 0.7MPa
- Response time: ≤15ms (exhaust to actuation)
- Weight: 1.2kg (including coil)
- Dimensions: 120mm(L) × 70mm(W) × 90mm(H)
- Seal material: FKM fluorocarbon rubber (high chemical resistance)
- Temperature range: -10℃ to 150℃ (extended thermal tolerance)
- Power consumption: ≤3.5W (energy-efficient design)
- Protection rating: IP67 (dustproof and waterproof)
- Port thread depth: 12mm (reinforced thread structure)
Industrial-grade high-pressure solenoid valve featuring forged brass body with triple-layer chrome plating. Engineered for extreme pressure stability with built-in manual override and surge protection. Requires 10μm filtration and 20-50 cSt viscosity hydraulic oil compatibility. Includes LED status indicator for operational monitoring.
- Hydraulic press control systems
- High-pressure water jet cutting equipment
- Construction machinery hydraulic circuits
- CNC machine tool clamping systems
- Offshore oil rig pneumatic controls
- Heavy-duty industrial automation lines
Installation protocol:
Must install vibration dampeners in high-shock environments.
Requires periodic lubrication (every 500k cycles) using ISO VG32 hydraulic oil.
Port alignment tolerance ≤0.5° to prevent thread galling.
| Property | Property Value |
|---|---|
| sku | 2SH05010A |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
