Airtac 2SH High Pressure Solenoid Valve 2SH05010C
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH05010C High-Pressure Solenoid Valve Specifications
- Model: 2SH05010C
- Type: 2-position direct-acting (Normally Closed)
- Port size: G1/8 (NPT1/8 optional)
- Operating pressure range: 0.5–21 MPa
- Maximum pressure rating: 25 MPa burst pressure
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Power consumption: DC: 6W / AC: 5.5VA
- Response time: ≤15ms (open/close)
- Seal material: FKM (Fluorocarbon Rubber)
- Body material: Anodized aluminum alloy (ISO-AlMg3.5Mn)
- Temperature range: -10℃ to 120℃ (non-freezing)
- Flow coefficient (Cv): 0.14
- Protection rating: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A (standard)
- Weight: 480g ±5%
- Dimensions: 80mm(L) × 45mm(W) × 65mm(H)
- Certifications: RoHS, CE, ISO/TS 16949
High-performance solenoid valve engineered for extreme pressure systems, featuring rapid response and reinforced sealing. The forged aluminum body withstands hydraulic shock, while the triple-layered FKM seals maintain integrity under thermal cycling. Requires 10μm filtration and compatible with ISO VG32-68 hydraulic fluids.
- Hydraulic pressurization systems (plastic injection molding machines)
- High-pressure lubrication control in CNC machining centers
- Oil & gas pipeline pressure regulation
- Industrial boiler safety cutoff systems
- Pressure testing equipment for automotive components
- High-pressure water jet cutting systems
Installation guidelines:
Mount in vibration-damped position using M5 shock-absorbing brackets (included).
Maintain ≥50mm clearance from adjacent components for heat dissipation.
Pre-flush system at 5MPa for 5 cycles before full-pressure operation.
| Property | Property Value |
|---|---|
| sku | 2SH05010C |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
