Airtac 2SH High Pressure Solenoid Valve 2SH05010CI
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH05010CI High Pressure Solenoid Valve Specifications
- Model: 2SH05010CI
- Type: 2-position 5-port direct-acting (high pressure series)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.5–12 MPa (72–1,740 psi)
- Maximum pressure: 15 MPa (2,175 psi) intermittent
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Flow coefficient (Cv): 0.65
- Seal material: Fluororubber (FKM) standard (NBR optional)
- Ambient temperature: -10℃ to 60℃ (non-freezing)
- Fluid temperature: 0℃ to 60℃
- Protection class: IP67 (coil protection)
- Electrical connection: DIN43650 Form A connector
- Weight: 320g ±5% (excluding accessories)
- Dimensions: 80mm(L) × 45mm(W) × 65mm(H)
- Port thread depth: 10mm minimum engagement
Industrial-grade high pressure solenoid valve featuring reinforced stainless steel core and anti-vibration design. Engineered for hydraulic/pneumatic hybrid systems requiring extreme pressure stability. Includes manual override button for emergency operation and status indicator LED (on select models). Requires 10μm filtration with water separation.
- Hydraulic pressurization systems in die casting machines
- High-pressure gas chromatography equipment
- CNC machine tool hydraulic clamping units
- Pressure testing rigs for aerospace components
- Injection molding machine accumulator controls
- Industrial boiler safety venting systems
Installation criticals:
Always install with pressure-relief sequence (P→A→B→R). Use copper crush washers (included)
for port sealing. Maintain minimum 15mm clearance from electromagnetic interference sources.
Pre-charge system to ≥0.3MPa before initial activation.
| Property | Property Value |
|---|---|
| sku | 2SH05010CI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
