Airtac 2SH High Pressure Solenoid Valve 2SH05015B
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH05015B High-Pressure Solenoid Valve Specifications
- Model: 2SH05015B
- Type: 5-port/3-position closed center (pneumatic pilot operated)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.5-21 MPa (72.5-3,046 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 1,800 Nl/min (ANR at 0.7MPa)
- Response time: ≤30ms (excitation), ≤50ms (de-excitation)
- Seal material: Fluorinated rubber (FKM) for high-pressure resistance
- Temperature range: -20℃ to 80℃ (non-freezing)
- Weight: 320g ±5%
- Dimensions: 78mm(L) × 52mm(W) × 38mm(H)
- Protection rating: IP67 (dustproof and waterproof)
- Port thread depth: 12mm (minimum engagement depth 9mm)
- Coil insulation class: Class F (155℃)
Heavy-duty high-pressure solenoid valve engineered for industrial hydraulic/pneumatic systems requiring extreme pressure stability. Features dual-coil latching design for continuous operation and reduced energy consumption. Internal pilot structure ensures reliable switching under pressure fluctuations. Compatible with ISO VG32 hydraulic oil and standard compressed air.
- Hydraulic press clamping systems
- High-pressure gas chromatography equipment
- Industrial boiler safety cutoff systems
- CNC machine tool hydraulic actuators
- Offshore platform pneumatic controls
Installation requirements:
Must be mounted horizontally with arrow aligned to flow direction.
Requires 15-20mm vibration absorption space. Pre-lubricate ports
when handling viscous media. Use locknuts with 15-20N·m torque.
- Replace seals every 5 million cycles or 2 years (whichever comes first)
- Use 10μm filtration for media containing particulates
- Coil replacement requires matching voltage code (stamped on DIN connector)
| Property | Property Value |
|---|---|
| sku | 2SH05015B |
| Port Size | PT 1/2 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
