Airtac 2SH High Pressure Solenoid Valve 2SH05015F
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH05015F High-Pressure Solenoid Valve Specifications
- Model: 2SH05015F
- Type: 5/2-way direct-acting solenoid valve (high-pressure series)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.5–21 MPa (7–3,046 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 1,200 NL/min (ANR)
- Response time: ≤15ms (at 20℃)
- Seal material: FKM fluorocarbon rubber (standard), optional HNBR
- Temperature range: -40℃ to 120℃ (non-freezing)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion)
- Weight: 300g ±5% (with connector)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H) (excluding fittings)
- Port thread depth: 12mm (ISO 228-1 standard)
- Hysteresis: ≤0.02 MPa
Industrial-grade high-pressure solenoid valve featuring dual-coil latching design for energy efficiency. Engineered with anti-vibration structure and pressure-balance mechanism, capable of handling viscous fluids and compressed gases. Includes manual override and LED status indicator. Requires 10μm filtration (ISO 8573-1 class 4).
- Hydraulic press control systems
- CNC machine tool clamping mechanisms
- High-pressure gas chromatography equipment
- Plastic injection molding machines
- Automotive brake testing rigs
- Industrial boiler pressure regulation
Installation requirements:
Mount with torque ≤2.5N·m using backup wrench. Maintain 20mm clearance
for heat dissipation. Always install downstream pressure regulator and
perform monthly seal integrity checks in continuous operation.
| Property | Property Value |
|---|---|
| sku | 2SH05015F |
| Port Size | PT 1/2 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
