Airtac 2ST Fluid Control Valve 2ST03006BI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03006BI Fluid Control Valve Technical Specifications
- Model: 2ST03006BI
- Type: 2-position 3-way (2ST series), normally closed
- Port configuration: P (pressure), A (actuator), R (exhaust)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 850 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil power: 1.6W (DC12V), 2.5W (DC24V)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Weight: 320g ±5% (including coil)
- Dimensions: 54mm(L) × 40mm(W) × 72mm(H) (body only)
- Mounting interface: ISO 15407-1 compliant sub-base
High-flow proportional control valve with precision spool design, optimized for dynamic pressure regulation in automated systems. Features anti-vibration coil structure and gold-plated terminals for reliable operation in high-humidity environments. Requires 5μm filtration (40μm for emergency use).
- Plastic injection molding machine pressure sequencing
- Automated assembly line clamping force control
- Semiconductor wafer handling vacuum/pressure switching
- Beverage filling system pressure modulation
- Textile machinery air cylinder synchronization
Installation guidelines:
Maintain horizontal piping alignment with arrow markings. Use M5 mounting screws with 0.6-0.8Nm torque.
Allow 15mm clearance below valve for maintenance access. Pre-charge system with 0.2MPa air before full activation.
Critical note:
Not compatible with phosphate ester-based lubricants. Perform weekly manual cycling
if operated less than 50 cycles/day. Maximum allowable leakage: 10cm³/min at 0.5MPa.
| Property | Property Value |
|---|---|
| sku | 2ST03006BI |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC24V |
