Airtac 2ST Fluid Control Valve 2ST03008BG
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03008BG Fluid Control Valve Technical Details
- Model: 2ST03008BG (Double solenoid version)
- Type: 5-port 2-position pilot-operated directional valve
- Port configuration: 2 exhaust ports, 2 outlet ports, 1 pressure port
- Port size: PT1/4 (G1/4 thread standard)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC24V (±10%), AC220V (50/60Hz)
- Coil power: 1.8W (standard), 2.2W (high-power option)
- Flow capacity: 750 L/min (Cv=1.3 at 0.5MPa)
- Response time: ≤30ms (excitation), ≤50ms (de-excitation)
- Seal materials: NBR (standard), optional FKM for high-temp
- Ambient temperature: -5℃ to 60℃ (operational), -20℃ to 80℃ (storage)
- Weight: 450g ±5% (including coil)
- Dimensions: 56mm(W) × 35mm(H) × 114mm(L)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
- Mounting options: Panel mount with M5 screws or DIN43650 adapter
High-flow directional control valve with dual solenoid operation, featuring brass body construction with hard anodized aluminum end caps. Designed for precise bi-directional pneumatic control in medium-pressure systems. Includes LED position indicator and manual override capability (optional). Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with dual-direction requirements
- Material handling cylinder control
- Test bench pressure regulation systems
Installation guidelines:
Maintain horizontal mounting position for optimal drainage.
Use flexible tubing connections to prevent mechanical stress.
Recommended maintenance cycle: 10 million cycles or 2 years
(whichever comes first) for seal replacement.
- Speed controller: ASC-200-04
- Quick-connect fitting: QST-04-B
- Mounting bracket: MB-35-AL
- Protective cover: PCV-24DC (for harsh environments)
| Property | Property Value |
|---|---|
| sku | 2ST03008BG |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC24V |
