Airtac 2ST Fluid Control Valve 2ST03008BI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03008BI Fluid Control Valve Specifications
- Model: 2ST03008BI
- Type: 2-position 3-way (2ST series), normally closed
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.05–0.8 MPa
- Max flow rate: 800 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±10%), AC220V (±10%)
- Coil insulation class: Class F (155℃)
- Weight: 205g ±5g (with coil)
- Dimensions: 53mm(L) × 34mm(W) × 65mm(H) (excluding ports)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced chemical resistance
- Ambient temperature range: -5℃ to 60℃ (non-freezing)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Port thread depth: 10mm (minimum engagement)
- Protection rating: IP67 (coil assembly)
High-flow proportional control valve with integrated silencer, featuring a copper-free aluminum alloy body for corrosion resistance in humid environments. The pilot-operated design ensures reliable switching under variable pressure conditions. Requires 5μm filtered compressed air with oil mist lubrication (ISO VG32 or equivalent).
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control in packaging systems
- Air blow cleaning circuits for CNC machines
- Medical gas distribution panels
- Beverage dispensing system actuators
Installation guidelines:
Mount horizontally with arrow marking aligned to airflow direction.
Use backup spanners during port connection to prevent body deformation.
Allow 15-minute stabilization period after first pressurization.
Critical note:
Not compatible with phosphate ester-based lubricants.
Minimum 2-second ON/OFF cycle required to prevent coil overheating.
| Property | Property Value |
|---|---|
| sku | 2ST03008BI |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC24V |
