Airtac 2ST Fluid Control Valve 2ST03008BIG
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03008BIG Fluid Control Valve Specifications
- Model: 2ST03008BIG
- Type: 3-position, 5-way (double solenoid)
- Port size: G1/8 (ISO standard)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5g
- Dimensions: 78mm(L) × 42mm(W) × 65mm(H)
- Seal material: FKM (Fluorocarbon Rubber) standard (NBR optional)
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Flow capacity: 750 L/min (ANR)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (dustproof/waterproof)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with dual solenoid activation, featuring brass body construction with chrome-plated spool for reduced friction. Includes manual override function and position detection switch compatibility. Designed for systems requiring precise mid-position control with 0.5mm orifice precision.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Food processing pneumatic circuits (FDA-compliant versions available)
- Semiconductor manufacturing equipment
- Automotive testing jig controls
Installation note:
Requires minimum 5μm filtration (40μm for basic applications).
Mounting orientation must allow 15° downward tilt for condensate drainage.
Use copper-free anti-seize compound on threads.
| Property | Property Value |
|---|---|
| sku | 2ST03008BIG |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC24V |
