Airtac 2ST Fluid Control Valve 2ST05010AI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05010AI Fluid Control Valve Specifications
- Model: 2ST05010AI
- Type: 2-position 5-way pilot-operated solenoid valve
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 380g ±5% (including coil)
- Dimensions: 60mm(L) × 45mm(W) × 80mm(H) (body only)
- Port thread depth: 12mm (minimum engagement length)
- Seal material: FKM (Viton® equivalent) for chemical resistance
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Flow capacity: 850 l/min (Cv=1.2 at 0.5MPa)
- Response time: ≤30ms (energize), ≤50ms (de-energize)
- Protection rating: IP67 (dustproof and temporary immersion)
- Electrical connection: DIN43650 Form A connector
High-flow proportional control valve with dual-pressure operation capability. Features corrosion-resistant aluminum alloy body with hard anodized finish and integrated silencer. Designed for applications requiring precise directional control and rapid cycling. Requires 5μm filtered compressed air with maximum 0.1ppm oil content.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Food processing pneumatic circuits (FDA-compliant variants available)
- Semiconductor manufacturing equipment
- High-speed packaging machinery
- Test bench pressure regulation systems
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (torque ≤1.2N·m).
Maintain minimum 50mm clearance below valve for exhaust flow.
Use copper-free anti-seize compound on threaded ports.
Perform weekly manual override checks in high-cycle applications.
Critical note:
Not compatible with phosphate ester-based lubricants.
Requires surge protection device when used with AC coils above 24V.
Maximum allowable leakage rate: 10 cm³/min at 0.5MPa.
| Property | Property Value |
|---|---|
| sku | 2ST05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC220V |
