Airtac 2ST Fluid Control Valve 2ST05010CI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05010CI Fluid Control Valve Specifications
- Model: 2ST05010CI
- Type: 2-position 5-way monostable (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Max flow rate: 1,000 L/min (ANR)
- Body material: Die-cast aluminum alloy (hard anodized)
- Seal material: Heat-resistant NBR (up to 120℃ intermittent)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Response time: ≤30ms (at 0.5MPa)
- Weight: 480g ±5%
- Dimensions: 76mm(L) × 45mm(W) × 84mm(H)
- Protection rating: IP67 (coil)/IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with dual-pressure operation capability, featuring a unique pressure-balanced spool design for consistent performance under varying loads. The hardened aluminum body withstands industrial vibration environments, while the extended temperature seals accommodate intermittent high-heat applications. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 air quality.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Food processing pneumatic circuits (oil-resistant version available)
- Lithium battery production equipment
- Textile machinery cylinder control
Installation note:
Lubricate pilot ports with ISO VG32 turbine oil before initial use.
Maintain minimum 15mm clearance below valve for condensate drainage.
Use M5 mounting screws with 0.8-1.2Nm torque specification.
| Property | Property Value |
|---|---|
| sku | 2ST05010CI |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC 110V |
