Airtac 2SX Fluid Control Valve 2SX03006BIG
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX03006BIG Fluid Control Valve Specifications
- Model: 2SX03006BIG
- Type: 3-position, 5-way closed center (Double solenoid pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (including coil)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -20℃ to 80℃ (non-freezing conditions)
- Power consumption: ≤2.5W (DC), ≤3.5VA (AC)
- Response time: ≤30ms (at 0.5MPa)
- Flow capacity: 850 l/min (ANR, at 0.5MPa)
- Protection rating: IP67 (coil protection)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with center-block function, featuring dual manual override and LED status indicator. The hardened aluminum body with nickel-plated brass core ensures durability in humid environments. Designed for systems requiring mid-position stability and emergency shutoff capability.
- Industrial robotic arm pneumatic circuits
- Plastic injection molding machine clamping units
- Food processing conveyor braking systems
- Automated test equipment with safety interlocks
- Semiconductor wafer handling vacuum/pressure switching
Installation guidelines:
Use ISO 15407-1 compliant mounting interface. Maintain minimum 15mm
clearance below valve for heat dissipation. Lubricate with ISO VG32
turbine oil if operating below -10℃. Perform monthly manual cycling
in high-humidity environments.
Critical note:
Requires 5μm filtration (40μm for emergency use only). Avoid axial
piping stress – use flexible tubing within 200mm of valve ports.
Center position not suitable for long-term energy-saving holding.
| Property | Property Value |
|---|---|
| sku | 2SX03006BIG |
| Port Size | PT1/8 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC24V |
