Airtac 2SX Fluid Control Valve 2SX03006C
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX03006C Fluid Control Valve Technical Details
- Model: 2SX03006C
- Type: 3-port, 2-position direct-acting solenoid valve
- Port configuration: G1/8 (ISO228/1 standard)
- Port thread depth: 10mm (minimum engagement)
- Operating pressure range: 0.05–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Flow capacity: 850 l/min (Cv=1.2 at 0.5MPa)
- Seal material: Fluororubber (FKM) standard (NBR optional)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Weight: 280g ±5% (excluding connector)
- Dimensions: 56mm(L) × 40mm(W) × 72mm(H) (including ports)
- Protection class: IP67 (coil assembly)
- Electrical connection: DIN43650 Form A connector
- Hysteresis: ≤10% of rated voltage
High-flow compact solenoid valve with dust-tight construction, featuring brass body with electroless nickel plating for corrosion resistance. The direct-acting design enables stable operation at low pressures (down to 0.05MPa), with reinforced coil structure for 100,000+ cycle durability. Includes manual override button for system debugging.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control for material handling
- Medical gas panel shut-off systems
- Beverage filling machine pressure regulation
- Textile machinery air flow management
Installation guidelines:
Mount with port axis aligned horizontally to prevent debris accumulation.
Use copper-free anti-seize compound on threads. Maintain minimum 20mm
clearance below valve for condensate drainage. Pre-filter air supply
to 5μm particle size maximum.
| Property | Property Value |
|---|---|
| sku | 2SX03006C |
| Port Size | PT1/8 |
| Flow Aperture | 1.5mm |
| Coil Voltage | AC 110V |
