Airtac 2SX Fluid Control Valve 2SX03006F
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX03006F Fluid Control Valve Specifications
- Model: 2SX03006F
- Type: 2-position 3-way normally closed (pilot-operated)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure range: 0.15–0.8 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 300g ±5% (including coil)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Seal material: NBR (Nitrile rubber), optional FKM available
- Temperature range: -20℃ to 70℃ (non-freezing)
- Power consumption: ≤2.5W (DC), ≤3.2VA (AC)
- Protection rating: IP65 (coil protection)
- Fluid compatibility: Compressed air (40μm filtered)
- Lubrication requirement: Oil mist lubrication (ISO VG32 recommended) or non-lubricated
- Response time: ≤15ms (at 0.5MPa)
- Cycle life: ≥5 million operations (under standard conditions)
High-flow fluid control valve with optimized pressure compensation, featuring an aluminum alloy body with hard anodized treatment for enhanced corrosion resistance. The low-hysteresis design ensures precise flow control in pneumatic systems, while the dual-seal structure prevents internal leakage. Compatible with both lubricated and non-lubricated air systems.
- Industrial automation assembly line controls
- Packaging machinery cylinder sequencing
- Medical equipment gas flow regulation
- Food processing pneumatic systems
- Semiconductor manufacturing actuators
- Elevator brake control systems
Installation guidelines:
Mount in vibration-free environments with proper pipe support.
For horizontal installation, use bracket support (AXF-04 accessory recommended).
Maintain ambient humidity below 85% RH. Allow 15mm clearance around valve for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2SX03006F |
| Port Size | PT1/8 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC12V |
