Airtac 2SX Fluid Control Valve 2SX03008B
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX03008B Fluid Control Valve Technical Details
- Model: 2SX03008B
- Type: 3-position, 5-way closed center (Double solenoid)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5 MPa)
- Response time: ≤15ms (at rated voltage)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion)
- Weight: 320g ±5g (with connectors)
- Dimensions: 56mm(L) × 42mm(W) × 78mm(H) (excluding fittings)
- Port thread depth: 10mm (straight thread with O-ring seal)
- Max cycling rate: 5Hz (300 cycles/minute)
- Fluid compatibility: Compressed air (ISO 8573-1:2010 Class 3.4.2)
High-performance directional control valve featuring dual-coil redundancy and zero-pressure reset capability. The 2SX03008B incorporates a manual override button for emergency operation and shock-resistant coil design for industrial environments. Optimized flow path reduces pressure drop by 18% compared to previous generation models. Requires 5μm filtered air with oil mist lubrication (ISO VG32 recommended).
- Multi-station pneumatic clamping systems
- Automated assembly line tooling changers
- Textile machinery cylinder control
- Semiconductor handling robots
- Plastic injection molding ejectors
- Test bench sequencing circuits
Installation guidelines:
Mount horizontally with coil axis vertical. Allow 15mm clearance below
exhaust ports for muffler attachment. Perform weekly manual cycling
during standby periods to prevent seal hardening. Avoid rapid
pressure fluctuations above 0.8 MPa.
| Property | Property Value |
|---|---|
| sku | 2SX03008B |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC24V |
