Airtac 2SX Fluid Control Valve 2SX03008F
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX03008F Fluid Control Valve Technical Details
- Model: 2SX03008F
- Type: 3-position, 5-way closed center (Double solenoid)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±2% (including connectors)
- Dimensions: 60mm(L) × 52mm(W) × 95mm(H)
- Flow capacity: 850 L/min (Cv=1.3 at 0.5MPa)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -10℃ to 80℃ (non-freezing environment)
- Response time: ≤30ms (at rated voltage)
- Protection rating: IP67 (dust tight & temporary immersion)
- Manual override: Built-in emergency switch
High-flow directional control valve with center-block function, featuring brass body construction with chrome-plated spool for reduced friction. Designed for bi-directional pneumatic cylinder control with position holding capability. Includes LED status indicator and surge protection circuit. Requires 5μm filtered compressed air with lubrication (ISO 8573-1 class 3.4.3).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Material handling equipment position locking
- Textile machinery tension control
- Automotive testing jig controls
Installation guidelines:
Mount horizontally with arrow aligned to airflow direction.
Use vibration-damping mounts in high-shock environments.
Allow 15mm clearance for heat dissipation during continuous operation.
Critical note:
Do NOT use with oxygen or combustible gases.
Maximum duty cycle: 100% at 25℃ ambient, derate by 20% per 10℃ above 40℃.
| Property | Property Value |
|---|---|
| sku | 2SX03008F |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC12V |
