Airtac 2SX Fluid Control Valve 2SX05010CI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX05010CI Fluid Control Valve Specifications
- Model: 2SX05010CI
- Type: 5-port/2-position (5/2-way) solenoid valve with center closed position
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: ISO 228/1 (BSPP)
- Operating pressure: 0.1–1.0 MPa (14.5–145 psi)
- Max flow rate: 750 L/min (Cv=1.3 at 0.5 MPa)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: HNBR (Hydrogenated Nitrile) with stainless steel plunger
- Temperature range: -10℃ to 80℃ (with no freezing condensation)
- Protection rating: IP67 (dustproof and waterproof)
- Weight: 320g ±5% (including coil)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H) (excluding fittings)
- Port alignment: ISO 5599/1 standard (compliant with DIN 24340)
- Manual override: Built-in emergency manual operator
High-flow proportional control valve featuring low power consumption and zero pressure differential operation. The 2SX05010CI's unique spool design minimizes internal leakage (<0.1 L/min at 0.5 MPa) while maintaining rapid response. Its corrosion-resistant aluminum body with hard anodized treatment ensures durability in humid environments. Requires 5μm filtered air with oil mist lubrication (ISO VG32 recommended).
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery air circuit switching
- Semiconductor handling equipment
- Food packaging machine actuators
Installation guidelines:
Maintain horizontal mounting position (±15° tolerance) with exhaust ports oriented downward.
Use flexible tubing for the first 300mm of connections to reduce vibration transmission.
For continuous operation, install a bypass circuit with redundant valves.
- Lubrication: Every 5 million cycles (or 6 months)
- Seal replacement: Every 15 million cycles (or 2 years)
- Coil inspection: Check insulation resistance (>100MΩ) annually
| Property | Property Value |
|---|---|
| sku | 2SX05010CI |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC 110V |
