Airtac 2WT Extra High Flow Solenoid Valve 2WT03006BIG
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT03006BIG Extra-Large Flow Solenoid Valve Specifications
- Model: 2WT03006BIG
- Type: 5/3-way (triple position) pilot-operated
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: Cv=4.8 (at 7 bar)
- Response time: ≤25ms (energize), ≤35ms (de-energize)
- Seal material: HNBR rubber (high-temperature variant available)
- Temperature range: -10℃ to 80℃ (extended to 120℃ with FKM seals)
- Protection rating: IP67 (dustproof & temporary immersion resistant)
- Weight: 1.25kg ±3%
- Dimensions: 128mm(L) × 52mm(W) × 84mm(H) (excluding connectors)
- Port thread depth: 15mm (straight thread with O-ring seal)
- Coil insulation class: Class F (155℃)
High-performance industrial valve engineered for heavy-duty pneumatic systems requiring massive airflow. Features a unique "triple cavity" design that reduces pressure loss by 30% compared to standard models. The aluminum alloy body with hard anodizing treatment ensures corrosion resistance in humid environments. Includes manual override and position-indication LED (DC models only).
- High-speed packaging machinery air circuits
- Injection molding machine clamp units
- Automotive tire assembly systems
- Industrial vacuum pump controls
- Foundry equipment pneumatic actuators
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use vibration-damping brackets in mobile applications. Requires
5μm filtration and automatic drain maintenance. Allow 15mm minimum
clearance around coil for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2WT03006BIG |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC24V |
