Airtac 2WT Extra High Flow Solenoid Valve 2WT03008A
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT Series High Flow Solenoid Valve 2WT03008A Specifications
- Model: 2WT03008A
- Type: 5/3-way (triple position closed center)
- Port size: G3/8 (BSPP thread)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 7500 L/min (ANR) at 0.5MPa
- Response time: ≤30ms (energize), ≤50ms (de-energize)
- Weight: 850g ±5% (including coil)
- Dimensions: 120mm(L) × 65mm(W) × 55mm(H)
- Seal material: Heat-resistant HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (coil protection)
- Max cycling rate: 5Hz (300 cycles/min)
- Flow coefficient (Cv): 12.5 (Kv=10.6)
- Equivalent SMC model: VFS5120-5DZ-03
Industrial-grade high flow solenoid valve engineered for heavy-duty pneumatic systems requiring rapid response and massive airflow. Features dual-coil latching design with manual override and surge protection circuitry. Optimized flow path geometry reduces pressure drop by 30% compared to standard valves. Requires 5μm filtration with automatic drain.
- Injection molding machine clamp mechanisms
- High-speed packaging line diverters
- Automotive tire assembly systems
- Industrial compressor bypass control
- Pneumatic pressurization systems for aerospace testing
Installation requirements:
Mount horizontally with arrow direction matching airflow.
Use vibration-damping brackets in mobile applications.
Maintain 1.5x port diameter clearance downstream for optimal flow.
Requires 20-30VA inrush current protection for AC coils.
| Property | Property Value |
|---|---|
| sku | 2WT03008A |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC220V |
