Airtac 2WT Extra High Flow Solenoid Valve 2WT03008B
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT Series Ultra-High Flow Solenoid Valve 2WT03008B Specifications
- Model: 2WT03008B
- Type: 5/3-way (center exhaust) direct-acting with manual override
- Port size: G3/8 (ISO228/1 standard)
- Flow capacity: 4500 NL/min (ANR) at 0.5 MPa
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 580g ±2%
- Dimensions: 98mm(L) × 54mm(W) × 82mm(H)
- Seal material: Heat-resistant HNBR (-20℃ to 120℃)
- Temperature range: -5℃ to 80℃ (with silicone grease)
- Response time: ≤15ms (open/close at rated voltage)
- Protection rating: IP67 (dust/immersion protected)
- Port thread depth: 12mm (minimum engagement)
- Max cycling rate: 5Hz (300 cycles/minute)
- Housing material: Die-cast aluminum alloy (anodized)
Engineered for industrial heavy-duty applications requiring massive airflow, the 2WT03008B features a 4mm oversized spool design achieving 30% higher flow than standard models. Its dual-coil structure ensures stable operation under voltage fluctuations (±10% tolerance). The corrosion-resistant aluminum body with integrated heat dissipation fins prevents overheating during continuous operation.
- High-speed packaging machinery cylinder control
- Plastic injection molding machine clamp systems
- Automotive tire assembly pneumatic circuits
- Industrial vacuum generator switching
- Pneumatic conveyor line diverters
Installation guidelines:
Mount horizontally with arrow aligned to airflow direction.
Use 2WT-ADP mounting bracket (sold separately) for vibration-prone environments.
Requires 5μm filtration (40μm for emergency use only).
| Property | Property Value |
|---|---|
| sku | 2WT03008B |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC24V |
