Airtac 2WT Extra High Flow Solenoid Valve 2WT03008C
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT Series Ultra-High Flow Solenoid Valve 2WT03008C Technical Details
- Model: 2WT03008C
- Type: 5/3-way (triple position closed center) with manual override
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.2–1.0 MPa (2–10 bar)
- Max flow rate: 1200 L/min (Cv=2.8)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 480g ±5% (excluding accessories)
- Dimensions: 98mm(L) × 45mm(W) × 82mm(H)
- Body material: Anodized aluminum alloy (ADC12)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-performance industrial-grade solenoid valve engineered for heavy-duty pneumatic systems requiring massive airflow. Features triple-position control with center-block function for precise cylinder positioning. The pilot-operated design ensures reliable switching even under pressure fluctuations. Includes emergency manual actuator and surge protection circuitry.
- Plastic injection molding machine clamp control
- Automotive assembly line heavy actuators
- High-speed packaging machinery (carton erectors, palletizers)
- Foundry equipment pneumatic systems
- Paper mill air cylinder clusters
- Test bench flow simulation systems
Installation guidelines:
Mount horizontally with arrow aligned to airflow direction. Use 40μm filter + 5μm lubricator (FRL unit).
Allow 15cm clearance for heat dissipation. Perform monthly manual cycling to prevent spool sticking.
Critical note:
Requires 0.1-1.0 MPa pilot pressure for stable operation. Not compatible with phosphate ester-based lubricants.
Maximum 100,000 switching cycles at full load (lubricated environment extends lifespan by 300%).
| Property | Property Value |
|---|---|
| sku | 2WT03008C |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC 110V |
